AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
EtherNet/IP interface
11.1.4 AS-i slave Object
Class Code: 101 (0x65)
64 instances for each AS-i circuit, 1 for each AS-i slave
Instance ID AS-i slave
1 slave 0, circuit 1
2 slave 1A, circuit 1
……
32 slave 31A circuit 1
33 empty, circuit 1
34 slave 1B, circuit
……
64 slave 31B, circuit 1
65 slave 0, circuit 2
……
96 slave 31A, circuit 2
97 empty, circuit 2
……
98 slave 1B, circuit 2
……
128 slave 31B, circuit 2
Tab. 11-15.
Attribute
ID
Access
Rule
Name DeviceNet
Data Type
Remark
100 get actual configuration UINT
101 get/set permanent configuration UINT slave 0, 32: not read-/
writeable
102 get/set actual parameters USINT
103 get/set permanent parameters USINT
104 get/set xID1 USINT slave 0: writeable only,
slave 0 - 32: readable
Tab. 11-16.
