Issue date: 17.4.2009
AS-Interface
EtherNet/IP interface
Hi-flags (8-bit)
LDS, LAS, LPS, LPF (64-bit)
Store actual parameter/store actual configuration/lock push-buttons
True: proceed the action
Hi-flags (8-bit)
2
2
2
1
2
0
AAe OL DX
Tab. 11-12.
AAe: Auto_Address_Enable
OL: Off-line
DX: Data_Exchange_Active
Operational mode (8-bit):
1: configuration mode
0: protected mode
LDS, LAS, LPS, LPF (64-bit)
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
0 7A6A5A4A3A2A1A0A
……
7 31B 30B 29B 28B 27B 26B 25B 24B
Tab. 11-13.
Change slave address (16-bit)
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
0 – B source address
1 – B target address
Tab. 11-14.
Meaning of the bit B
B = 0: Single AS-i slave or A-slave
B = 1: B-slave
