AS-Interface
Operation in advanced display mode
9.9.7.3 CONTROL FLAGS (control program flag memory)
Main menu || SETUP || AS-I CONTROL || CONTROL FLAGS ||
This function is used to read and modify the control program's flag memory.
• First, a row needs to be selected using the soft keys.
• Pressing OK displays the selected row.
After pressing OK, the display mode changes and it is now possible to select indi-
vidual flags using the soft keys. The selected flag is then displayed in binary for-
mat at the top row.
• Pressing OK again enables editing the selected binary value.
9.9.8 LOS (list of offline slaves)
Main menu || SETUP || LOS LIST OF OFFLINE SLAVES ||
CONTROL FLAGS
0:2A 47 2B 2C
4:83 BD F2 58
...
124: 4A C3 84 7A
5:10111101
4:83 [BD] F2 58
LOS LIST OF
OFFLINE SLAVES
CLEAR ALL
SET ALL
| 1A- X
2A- | 3A-
4A-X | 5A- X
....
30A-X | 31A-
| 1B- X
2B- X | 3B- X
4B- X | 5B- X
....
30B- X | 31B- X
