Issue date: 17.4.2009
120
Subject to reasonable modifications due to technical advances. © Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 Internet http://www.pepperl-fuchs.com
AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
EtherNet/IP interface
11.1.3 AS-i Master Object
Class code: 100 (0x64)
1 instance for each AS-i circuit
EC-flags (16-bit)
Attribute
ID
Access
rule
Name DeviceNet
data type
Default
data value
100 (0x64) get ec-flags UINT (16-bit)
101 (0x65) get/set hi-flags USINT
102 (0x66) get/set operational mode BOOL
103 (0x67) get LDS ULINT
104 (0x68) get/set LPS ULINT
105 (0x69) get LAS ULINT
106 (0x6A) get LPF ULINT
107 (0x6B) get/set Store_Actual_Configuration BOOL
108 (0x6C) get/set Store_Actual_Parameters BOOL
109 (0x6D) get/set Change_Slave_Adress UINT
110 (0x6E) get/set Lock push-buttons BOOL
Tab. 11-10.
EC-flags (16-bit)
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
DA NSE OV EF – – – Pok OR APF NA CA AAv AAs S0 Cok
Tab. 11-11.
Pok: Periphery_Ok
S0: LDS.0
AAs: Auto_Address_Assign
AAv: Auto_Address_Available
CA: Configuration_Active
NA: Normal_Operation_Active
APF: APF
OR: Offline_Ready
Cok: Config_Ok
EF: Earth falut
OV: Overvoltage
NSE Noise
DA: Double address
