AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
Function and startup of the Safety Monitor
8.7.1.2 Data not compatible
If a card is found whose data are incompatible with the device, the following error
message is displayed:
8.7.1.3 Card empty
The following message is displayed for an empty card:
From this time on all changes are made both in the device and on the chip card.
8.7.1.4 Data compatible
If when starting with an empty device (e.g. after a factory reset) a non-empty card
is found whose data are compatible with the device, the following message is dis-
played:
The card configuration is written to the device. From this time on all changes are
made both in the device and on the chip card.
8.7.1.5 Data in the device and on the chip card identical
If the card and device are not empty at start and the data are identical, no mes-
sage is displayed.
8.7.1.6 Data in the device and on the chip card not identical
If the card and device are not empty at start and the data are not identical, an er-
ror message is displayed and the card is not synchronized with the device. The
following menu is then automatically opened:
CHIPCARD NOT
COMPATIBLE
CHIPCARD FOUND
AS-I DATA WILL
BE SYNCHRONIZED
AS-I DATA FROM
CHIPCARD TAKEN
