AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
Operation in advanced display mode
9.5.1 TEACH CODES
The TEACH CODES menu enables teaching of code sequences using the dis-
play.
9.5.1.1 TEACH CODES – COMPLETE
Main Menu || AS-I SAFETY || TEACH CODES || TEACH CODES COMPLETE ||
In the sub-menu TEACH CODES COMPLETE you teach the code tables for all
included safety AS-i slaves.
First enter the PIN and confirm with OK.
If the PIN was correctly entered, the Monitor is stopped and the following informa-
tion appears:
TEACH CODES
COMPLETE
SINGLE SLAVE
COUPLING SLAVE
SNGL SLAVE CODE
TEACH CODES
ENTER PIN
0000
OK
To Next Page
