AS-Interface
Operation in advanced display mode
All safety contacts (also in sequence) must be closed for the safety unit to learn
the code sequences. Incomplete code tables are not learned.
Press on ESC/Service to quit learning. It is then possible to restart the Monitor:
TEACHING CODES
CLOSE CONTACTS
AS-I 1:
|1-OK
2-RX | 3-RR
.... |
30-DC |31-DC
AS-I 2:
|1-OK
2-RX | 3-RR
.... |
30-DC |31-DC
....
HELP
NO SAFETY SL
MS MISSING SLAVE
X CH OK
R CH RELEASED
OK CODE LEARNED
ER CODE ERROR
DC DUPL.CODE
Information!
If all safety AS-i slaves have been successfully taught, the first line in the display
changes from TEACHING CODES to CODES LEARNED.
START MONITOR?
OK
Information!
See also
<Procedure for configuring and teaching code sequences>.
