Subject to reasonable modifications due to technical advances. © Pepperl+Fuchs, Printed in Germany
129
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 Internet http://www.pepperl-fuchs.com
Issue date: 17.4.2009
AS-Interface
EtherNet/IP interface
Coding of status bytes
Bit [0 ... 3] State or color
0 green permanent lighting
1 green flashing
2 yellow permanent lighting
3 yellow flashing
4 red permanent lighting
5 red flashing
6grey or off
7 reserved
Bit [6] status or color
0 no device flashing yellow
1 at least one device flashing yellow
Bit [7] status or color
0 no device flashing red
1 at least one device flashing red
Tab. 11-28.
Safety control
Byte description
1 byte from the EtherNet/IP
bit 0: 1.Y1
bit 1: 1.Y2
bit 2: 2.Y1
bit 3: 2.Y2
bit 4 ... 7: reserved
Tab. 11-29.
