VARI❋LITE - VL440 / VL770 / VL880 SPOT LUMINAIRES SERVICE MANUAL
84 02.9687.0010 0
Top Assembly
Included Items Kit
28.9687.0440 Rev A (for VL440 Spot only)
28.9687.0770 Rev A (for VL770 Spot only)
28.9687.0880 Rev A (for VL880 Spot only)
Refer to Figure 3-7.
No. Item Qty. UM. Description
1 02.8001.0001 1 EA PRODUCT SUPPORT SHEET, VARI-LITE CUSTOMER SERVICE
2 02.8001.0002 1 EA VARI-LITE QUALITY ASSURANCE SHEET
3 02.8052.0001 1 EA CARD, LIMITED WARRANTY
4 02.8700.0001 1 EA CARD, PRODUCT REGISTRATION
5 02.9697.0002 1 EA UNPACK/QUICK START SHEET, VL440 / VL770 / VL880 SPOT
- 04.4037.0001 5 EA LABEL, 2.5 X .5 BARCODE (not shown)
- 04.9678.1001 2 EA LABEL, GREEN ROHS COMPLIANT (not shown)
- 06.9687.0001 1 EA SHIPPING FOAM (not shown)
- 07.5044.0001 1 EA BAG, DESICCANT, SHIPPING BOX (not shown)
- 07.9687.0001 1 EA CARDBOARD SHIPPING BOX, VL440/VL770/VL880 (not shown)
6 08.9687.0001 1 EA CD-ROM, VL440/VL770/VL880 PRODUCT DOCUMENTATION, USER
7 22.9687.0805 2 EA FAB ASSY, BRACKET TRUSS HOOK
8 52.6541.0001 1 EA CONN., BLUE CABLE POWER INLET POWERCON
9 71.9687.0400 1 EA LAMP, PHILIPS MSR400SA PGJ28 (VL440 SPOT ONLY)
71.9687.0700 1 EA LAMP, PHILIPS MSR700SA PGJ28 (VL770 SPOT ONLY)
71.9687.0800 1 EA LAMP, PHILIPS PLATINUM 35 800W PGJ28 (VL880 SPOT ONLY)
