Philips Vari-Lite VL440 - Right Tilt Bearing Assembly

HEAD ASSEMBLY : RIGHT TILT BEARING ASSEMBLY
02.9687.0010 0 109
3
Right Tilt Bearing Assembly
21.9687.1633 Rev A
Refer to Figure 3-25.
No. Item Qty. UM. Description
1 10.9628.0211 1 EA STABILIZER, PAN/TILT
2 10.9687.0652 1 EA BRACKET, SENSOR, TILT HOMING
3 10.9687.0657 1 EA PLATE, BEARING MOUNT
4 10.9687.0658 1 EA PLATE, HOMING TILT
5 10.9687.0660 1 EA TILT STOP
6 10.9687.0662 1 EA TILT TUBE
7 10.9687.1659 1 EA RETAINER, TILT BEARING, SMOOTH
8 25.9687.0019 1 EA SENSOR SWITCH, SLOTTED OPTICAL
9 53.6527.0001 3 EA SCREW, 6-32 X 1/2" SCSS, LOW PROFILE
10 53.6545.0003 4 EA SCREW, 8-32 X 3/8" PFZ
11 53.6559.0001 3 EA SCREW, 4-40 X 1/4" PFZ
12 53.6592.0250 2 EA SCREW, 4-40 X 1/4" PPB SEMS
13 53.6609.0001 2 EA SCREW, 6-32 X 3/8" PFZ
14 54.9687.0250 1 EA BEARING, 68072RS
15 54.9687.0251 1 EA PULLEY, TILT, 108T - GT2P
16 55.6603.0001 1 EA SPRING, SS 4.6#/IN EXL
