Lamp Housing Assembly
21.9687.0652 Rev J
Refer to Figure 3-27
No. Item Qty. UM. Description
1 10.9687.0605 1 EA PLATE, BULKHEAD, REFLECTOR
2 10.9687.0608.01 1 EA FAN BRACKET, DUAL BLOWER
3 10.9687.0608.02 1 EA BRACKET, DUAL BLOWER
4 10.9687.0640 2 EA CLIP, REFLECTOR RETAINER
5 10.9687.0671 2 EA STANDOFF, REAR PLATE
6 10.9687.0681 6 EA BRACKET, IGNITOR
7 10.9687.0691 1 EA PLATE, LAMP ADJUST
8 10.9687.0698 2 EA STANDOFF, REAR PLATE, STEEL
9 10.9687.0699 3 EA SPACER, LAMP ADJUST
10 10.9687.1611 1 EA INSULATION BLANKET, HOT BOX
11 10.9687.1613 1 EA FAN BRACKET, INSULATOR
12 10.9687.1672.XX 1 EA PLATE, REAR (NOTE, PART OF TOP ASSEMBLY, SHOWN FOR REFERENCE
ONLY)
13 22.9687.0610 1 EA ASSY, REFLECTOR SHIELD
14 42.9687.0200 1 EA REFLECTOR, FACETED, SVL
15 53.2004.0002 4 EA NUT, 8-32 KEPS ZINC PLATED
16 53.2030.0001 3 EA NUT, ACORN 10-32 THD 3/8" WIDE
17 53.6525.0188 2 EA SCREW, 6-32 X 3/16" LG PPZ
18 53.6558.0009 6 EA SCREW, 6-32 X 3/8" LG PPZ SEMS
19 53.6575.0007 2 EA SCREW, 8-32 X 7/8" LG PPZ SEMS
20 53.6575.0009 2 EA SCREW, 8-32 X 3/8" LG PPB SEMS
21 53.6594.0003 3 EA SCREW, 10-32 X 1-1/2" PPZ
22 53.6682.0025 4 EA SCREW, 8-32 X 5/8" PPZ SEMS
23 55.2233.2001 2 EA DZUS RAPIER MINI CLIP ON RETAINER
24 55.2233.2006 2 EA DZUS RAPIER SNAP IN RETAINER
25 55.3301.0010 3 EA #10 0.203 X 0.407 X 0.032 FLAT WASHER, STAINLESS STEEL
26 55.6528.0001 2 EA WASHER, #6 FLAT ZINC
27 55.6541.0008 1 EA GROMMET, 1/2" ID, 7/8" OD, 11/32" THK
28 55.6541.0011 1 EA GROMMET, 1/2" ID, 13/16" OD, 5/8" X 1/16" GRV SIL
29 55.9687.0606 3 EA SPRING, CPRSN, 0.36" OD X 1.5" LG X 0.042 WIRE
