Philips Vari-Lite VL440 - Generic Luminaire Assembly

TOP ASSEMBLY : GENERIC LUMINAIRE ASSEMBLY
02.9687.0010 0 103
3
Generic Luminaire Assembly
21.9687.0010 Rev D
Refer to Figure 3-22
No. Item Qty. UM. Description
1 21.9687.0650 1 EA ASSY, HEAD FRAME
2 21.9687.0751 1 EA ASSY, TILT LOCK
3 21.9687.0850 1 EA ASSY, UPPER ENCLOSURE
4 22.9687.0701 1 EA ASSY, YOKE
5 22.9687.0705 1 EA ASSY, FILLER, YOKE, SLOTTED
6 53.6543.0003 4 EA SCREW, 6-32 X 3/16" PPB
7 53.6575.0009 7 EA SCREW, 8-32 X 3/8" PPB SEMS
8 53.6608.0001 4 EA SCREW, 6-32 X 3/8" PFB
9 53.6682.0037 6 EA SCREW, 10-32 X 1/2" LG PPZ SEMS
