HEAD ASSEMBLY : ZOOM ASSEMBLY
02.9687.0010 0 129
3
Zoom Assembly
21.9687.0160 Rev D
Refer to Figure 3-38
No. Item Qty. UM. Description
1 10.9687.0102 1 EA PLATE, END, ZOOM
2 10.9687.0103 1 EA CARRIER, GROUP ONE
3 10.9687.0110 1 EA PLATE, BOTTOM, ZOOM
4 10.9687.0112 1 EA BRACKET, SUPPORT, GROUP THREE
5 10.9687.0134 1 EA BRACKET, ZOOM, HOME
6 10.9687.0160 1 EA PLATE, GROUP THREE
7 10.9687.0192 1 EA BRACKET, ZOOM MOTOR MOUNT
8 10.9687.0194 3 EA STANDOFF, FLAG STOP
9 10.9687.0195 1 EA BRACKET, FAN, GROUP ONE
10 10.9687.1107 1 EA CARRIER, GROUP TWO
11 10.9687.1135 1 EA TAB, HOMING, ZOOM
12 10.9687.0406 1 EA HOUSING, BEARING COLOR MIX SHAFT
13 21.9687.0151 1 EA ASSY, PRISM
14 21.9687.0152 1 EA ASSY, FROST
15 21.9687.0180 1 EA ASSY, LINEAR SLIDE, ZOOM
16 22.9687.0101 1 EA ASSY, POSITIONING CAM
17 22.9687.0106 1 EA ASSY, DRIVE GEAR, ZOOM
18 22.9687.0120 1 EA ASSY, GROUP ONE, LENS
19 22.9687.0121 1 EA ASSY, GROUP TWO, LENS
20 22.9687.0122 1 EA ASSY, GROUP THREE, LENS
21 25.9687.0020 3 EA SWITCH, SLOTTED, OPTICAL
22 44.9687.1209 2 EA MOTOR SIZE-17, SHAFT 0.70"
23 44.9687.1215 1 EA MOTOR SIZE-17, ZOOM
24 53.2200.0006 6 EA NUT, KEPS, 6-32
25 53.6404.0003 3 EA SCREW, 4-40 X 1.0" PPZ
26 53.6545.0003 4 EA SCREW, 8-32 X 3/8" PFZ
27 53.6558.0007 4 EA SCREW, 6-32 X 1/4" PPZ SEMS
28 53.6558.0009 2 EA SCREW, 6-32 X 3/8" PPZ SEMS
29 53.6559.0001 5 EA SCREW, 4-40 X 1/4" PFZ
30 53.6575.0009 2 EA SCREW, 8-32 X 3/8" PPB SEMS
31 53.6575.0010 2 EA SCREW, 8-32 X 1/2" PPZ SEMS
To Next Page
