VARI❋LITE - VL440 / VL770 / VL880 SPOT LUMINAIRES SERVICE MANUAL
90 02.9687.0010 0
VL770 Spot Luminaire
20.9687.0003 Rev H
Refer to Figure 3-11, Figure 3-12 and Figure 3-13.
No. Item Qty. UM. Description
1 04.9687.0110 1 EA PRODUCT ID LABEL, MODEL VL770 SPOT
2 10.9687.0720 2 EA YOKE ARM COVER
3 10.9687.0850 2 EA BASE COVER, DISPLAY SIDE
4 10.9687.0852 2 EA BASE COVER, HANDLE SIDE
5 10.9687.0855 2 EA SCREEN, INLET / EXHAUST
6 10.9687.1102 1 EA AIR DEFLECTOR, SVL
7 10.9687.1672.07 1 EA REAR PLATE, VL770
8 21.9687.0010 1 EA ASSY, SVL, GENERIC LUMINAIRE
9 21.9687.0160 1 EA ASSY, ZOOM
10 21.9687.0260 1 EA ASSY, TRANSFER FANS
11 21.9687.0301 1 EA ASSY, GOBO MODULE
12 21.9687.0511 1 EA ASSY, CYMD MODULE
13 21.9687.0620 1 EA ASSY, HEAD COVER, FRONT
14 21.9687.0625 1 EA ASSY, HEAD COVER, REAR
15 21.9687.0630 1 EA ASSY, LAMP COVER
16 21.9687.1630 1 EA BLOWER ASSY, DUAL, GOBO COOLING
- 25.9687.0004 1 EA CABLE ASSY, BALLAST COMM (not shown)
- 25.9687.0008 1 EA CABLE ASSY, TILT (not shown)
- 25.9687.0009 1 EA CABLE ASSY, EDGE (not shown)
- 25.9687.0010 1 EA CABLE ASSY, ZOOM GROUP (not shown)
- 25.9687.0011 1 EA CABLE ASSY, CMYD GROUP (not shown)
- 25.9687.0012 1 EA CABLE ASSY, GOBO GROUP (not shown)
- 25.9687.0015 1 EA CABLE ASSY, LAMP TO FANS (not shown)
- 25.9687.0021.07 1 EA VL440 - 770 LAMP SOCKET ASSEMBLY (not shown)
- 28.9687.0770 1 EA INCLUDED ITEMS KIT, VL770 SPOT (not shown)
17 40.9687.0003 1 EA FAN, AXIAL, 50 MM X 15 MM
18 53.2200.0004 1 EA NUT, KEPS, #4-40
19 53.2200.0008 2 EA NUT, KEPS, #8-32, KEPS SS
20 53.6517.0001 2 EA SCREW, 10-32 X 3/8 PPZ
21 53.6553.0008 2 EA SCREW, 10-32 X 9/16" PFB
22 53.6575.0003 2 EA SCREW, 8-32 X 7/8" PPZ
