CABLE ASSEMBLIES : TILT CABLE ASSEMBLY
02.9687.0010 0 155
3
Tilt Cable Assembly
25.9687.0008 Rev A
Refer to Figure 3-56
Figure 3-56: Tilt Cable Assembly
Note: Cables are only available as complete assemblies. The information contained in this
section is for reference only.
