Philips Vari-Lite VL440 - Rear Head Cover Assembly

TOP ASSEMBLY : REAR HEAD COVER ASSEMBLY
02.9687.0010 0 99
3
Rear Head Cover Assembly
21.9687.0625 Rev A
Refer to Figure 3-18
Figure 3-18: Rear Head Cover Assembly
No. Item Qty. UM. Description
1 07.5049.0001 1 EA LANYARD, NYLON, 8-INCH LONG
2 10.9687.0625 1 EA HEAD COVER, REAR
3 53.5655.0250 1 EA SCREW, #6 X 1/4" PPZ PLASTIC
4 55.2011.0003 1 EA SNAP, SPRING 3/16" EYE DIA
5 55.2233.2003 2 EA DZUS RAPIER 1/4-TURN STUD RETAINER, 5 MM
6 55.2233.2005 2 EA DZUS RAPIER 1/4-TURN STUD, 5 MM, 12 MM LG
1
6 (x2)
3
2
4
5 (x2)
