ENCLOSURE ASSEMBLY : UPPER ENCLOSURE ASSEMBLY
02.9687.0010 0 139
3
Enclosure Assembly
Upper Enclosure Assembly
21.9687.0850 Rev N
Refer to Figure 3-44, Figure 3-45 and Figure 3-46
No. Item Qty. UM. Description
1 04.9687.0100 1 EA OVERLAY, INPUT PANEL VL400/700
2 04.9687.0150 1 EA PRODUCT COMPLIANCE LABEL
3 10.9687.0814 1 EA ADAPTOR, YOKE
4 10.9687.0819 1 EA PLATE, BOTTOM, UPPER ENCLOSURE
5 10.9687.1820 1 EA PLATE, TOP UPPER ENCLOSURE
6 10.9687.0823 6 EA STANDOFF, UPPER ENCLOSURE
7 10.9687.0824 4 EA STANDOFF, PAN MOTOR
8 10.9687.0825 2 EA CAP,. BEARING, PAN
9 10.9687.0827 1 EA PULLEY, PAN, 108T-GT2P
10 10.9687.0828 1 EA COVER, PAN PULLEY
11 10.9687.0829 1 EA WIRE TRAY
12 10.9687.0836 4 EA STANDOFF, BLOWER ASSY.
13 10.9687.0840 4 EA MOUNTING BUTTON
14 10.9687.0841 1 EA PAN LATCH
15 10.9687.0860 4 EA TEFLON SPACER, PAN LOCK
16 10.9687.0861 2 EA LATCH SPRING, PAN LOCK
17 10.9687.1811 1 EA STABILIZER, 50 MM DIA
18 10.9687.1825 1 EA CAP, BEARING, PAN, INSIDE
19 21.9687.0860 1 EA ASSY, PAN MOTOR
20 22.9687.0807 1 EA ASSY, PAN TUBE
21 22.9687.0810 1 EA ASSY, PANEL, DISPLAY CONNECTOR
22 22.9687.0811 1 EA ASSY, BLOWER DEFLECTOR, RIGHT
23 22.9687.0812 1 EA ASSY, BLOWER DEFLECTOR, LEFT
24 24.9664.4895 1 EA PCB ASSY, DMX INPUT
25 24.9690.0580 1 EA BRD ASSY, VLX DISPLAY
- 25.9661.1520 1 EA CABLE ASSY, ENCLOSURE TO YOKE CHASSIS GROUND (not shown)
26 25.9687.0001 1 EA CABLE ASSY, AC INPUT
- 25.9687.0003 1 EA CABLE ASSY, DMX/DISPLAY COMM (not shown)
