VARI❋LITE - VL440 / VL770 / VL880 SPOT LUMINAIRES SERVICE MANUAL
118 02.9687.0010 0
Gobo Module Assembly
21.9687.0301 Rev J
Refer to Figure 3-30 and Figure 3-31
No. Item Qty. UM. Description
1 10.9687.0202 1 EA PLATE, MOTOR MOUNT, FIXED GOBO
2 10.9687.0229 4 EA STANDOFF, MOTOR REAR, SENSOR
3 10.9687.0230 2 EA BRACKET, SENSOR, HOMING
4 10.9687.0233 2 EA SPACER, MOTOR SHAFT
5 10.9687.0237 1 EA STABILIZER, FIXED GOBO
6 10.9687.0238 1 EA STABILIZER, RETAINER
7 10.9687.0240 1 EA LINK, IRIS CONTROL
8 10.9687.1201 1 EA PLATE, GOBO MODULE
9 21.9687.0256 1 EA WEDGE FIXED COLOR WHEEL
10 21.9687.0257 1 EA ROTATING GOBO WHEEL
11 21.9687.0258 1EAFIXED GOBO WHEEL
12 22.9687.0201 1 EA ASSY, OUTDRIVE, FIXED GOBO
13 22.9687.0202 1 EA ASSY, OUTDRIVE, GOBO ROTATE
14 22.9687.0203 1 EA ASSY, CONTROL ARM, IRIS
15 22.9687.0204 2 EA ASSY, PLATE, HOMING, MOTOR REAR
16 22.9687.0222 1 EA ASSY, COAX, GOBO ROTATE
17 22.9687.0230 1 EA ASSY, IRIS, 25MM FIXED APERTURE
18 24.9678.3240 1 EA PCB ASSY, WHEEL POSITION SENSOR
19 25.9687.0020 3 EA SWITCH, SLOTTED OPTICAL
20 25.9687.0024 3 EA CABLE ASSY, INDEX SENSOR
21 44.9687.1204 2 EA MOTOR, SIZE-17, SHAFT 0.455"
22 44.9687.1210 2 EA MOTOR, DUAL SHAFT
23 44.9687.1213 1 EA MOTOR, SIZE-14, SHAFT 0.50" LG
24 53.5638.0252 4 EA SCREW, 6-32 X 1/4" PFS UNDERCUT
25 53.6558.0009 3 EA SCREW, 6-32 X 3/8" LG PPZ SEMS
26 53.6575.0009 4 EA SCREW, 8-32 X 3/8" PPB SEMS
27 53.6592.0250 8 EA SCREW, 4-40 X 1/4" PPB SEMS
28 53.6598.0187 8 EA SCREW, 4-40 X 3/16" PFB
29 53.6659.0005 2 EA SCREW, 2-56 X 1/4" PFZ
30 53.6659.0008 3 EA SCREW, 2-56 X 3/16" PFZ
31 54.9687.0253 4 EA BEARING, MR105ZZ
