HEAD ASSEMBLY : GOBO MODULE ASSEMBLY
02.9687.0010 0 119
3
Important Notes About the Gobo Module Assembly:
• When replacing either Rotating Gobo or Fix Color Motor, ensure the rear homing plate is installed
with the set screw to the flat part of motor shaft when tab is in sensor.
• When replacing Fixed Gobo Motor, ensure the Fixed Gobo Outdrive is installed with set screw to
flat part of motor shaft when tab is in optical sensor.
• When replacing Index Motor, ensure the Index Outdrive is installed with set screw to flat part of
motor shaft.
32 55.1000.0009 1 EA SPRING, COMPRESS SS 316
33 55.2123.0013 8 EA WAVE SPRING, 0.265" ID X 0.367" OD X 0.006" THK
34 55.2179.0001 2 EA CABLE ANCHOR MOUNT, #6 SCREW
35 55.3301.0010 2 EA #10 0.203" X 0.407" X 0.032" FLAT WASHER SS
36 55.6546.0004 2 EA WASHER, TEFLON, 0.201" ID X 0.433" OD
No. Item Qty. UM. Description
To Next Page
