Philips Vari-Lite VL440 - Tilt Motor Assembly

HEAD ASSEMBLY : TILT MOTOR ASSEMBLY
02.9687.0010 0 115
3
Tilt Motor Assembly
21.9687.0670 Rev C
Refer to Figure 3-28.
No. Item Qty. UM. Description
1 10.9687.0655 1 EA BRACKET, MOTOR MOUNT, TILT
2 21.9687.0655 1 EA PULLEY, PINION (INCLUDES ENCODER WHEEL AND SET SCREWS)
3 24.9661.5000 1 EA BRD ASSY, PAN/TILT ENCODER
4 44.9678.1680 1 EA MOTOR, 3 PHASE, SIZE 23 HIGH TORQUE
5 53.6575.0010 3 EA SCREW, 8-32 X 1/2" LG PPZ SEMS
6 53.6592.0250 2 EA SCREW, 4-40 X 1/4" LG PPB SEMS
7 55.2204.0001 2 EA WASHER, #4 NYLON
