HEAD ASSEMBLY : LAMP HOUSING ASSEMBLY
02.9687.0010 0 113
3
Note: Items 12 and 30 are shown for assembly reference only. These items are part of the top-level
luminaire assembly and are specific to their respective fixture. See “Top Assembly” on page 84 for
more information.
30 25.9687.0021.XX 1 EA LAMP SOCKET ASSEMBLY (NOTE, PART OF TOP ASSEMBLY, SHOWN FOR
REFERENCE ONLY)
No. Item Qty. UM. Description
To Next Page
