Philips Vari-Lite VL440 - Page 99

DRAWING TREES : VL770 SPOT LUMINAIRE DRAWING TREE
02.9687.0010 0 81
3
VL770 Spot Luminaire Drawing Tree (continued)
Figure 3-4: VL770 Spot Luminaire Subassembly Drawing Tree Part 2
Left Flag Motor Plate Assembly
21.9687.1435 Rev A
Pulley Pinion Assembly
21.9687.0655 Rev. A
Pan Motor Assembly
21.9687.0860 Rev. B
Pulley Pinion Assembly
21.9687.0655 Rev. A
Head Frame Assembly
21.9687.0650 Rev N
Upper Enclosure Assembly
21.9687.0850 Rev N
Chassis To Yoke Ground Cable
Assembly
25.9661.1520 Rev D
Generic Luminaire Assembly
21.9687.0010 Rev D
Continued from previous page
Left Tilt Bearing Assembly
21.9687.0632 Rev A
Right Tilt Bearing Assembly
21.9687.1633 Rev A
Linear Roller Assembly
21.9687.0634 Rev B
Lamp Housing Assembly
21.9687.0652 Rev J
Tilt Motor Assembly
21.9687.0670 Rev C
Slotted Optical Switch Cable
Assembly
25.9687.0020 Rev A
AC Input Cable Assembly
25.9687.0001 Rev A
DMX / Display Comm Cable
Assembly
25.9687.0003 Rev A
36 Volt Supply Cable Assembly
25.9687.0005 Rev A
Ballast to Ignitor Cable Assembly
25.9687.0006 Rev A
Pan Motor Cable Assembly
25.9687.0007.01 Rev C
Pan Encoder Cable Assembly
25.9687.0007.02 Rev C
APS Fan Cable Assembly
25.9703.0002 Rev B
AUX Comm Interface Cable
Assembly
25.9703.0016 Rev A
CYMD Color Module Assembly
21.9687.0511 Rev C
Slotted Optical Switch Cable
Assembly
25.9687.0020 Rev A
Right Flag Motor Plate Assembly
21.9687.1437 Rev A
Slotted Optical Switch Cable
Assembly
25.9687.0020 Rev A
Slotted Optical Switch Cable
Assembly
25.9687.0020 Rev A
Continued from
previous page
