Pixsys MCM260X - Analog Input Parameters; Analog Input Settings

24 - MCM260X - Manuale d’uso
6.2 UNIT B - ANALOG INPUTS
21 AI1 input lower limit (Word modbus )
22 AI2 input lower limit (Word modbus )
Analog input lower limit. E.g.: with input 0..10 V this parameter indicates the value assumed by
the input in line with 0V
-32767..+32767, Default: 0.
23 AI1 input upper limit
(Word modbus )
24 AI2 input upper limit (Word modbus )
Analog input upper limit. E.g.: with input 0..10 V this parameter indicates the value assumed by
the input in line with 10V
-32767..+32767. Default:10000
25 Liner limit beyond limits AI1
(Word modbus )
26 Liner limit beyond limits AI2 (Word modbus )
In case of linear input, it allows the process to exceed the limits (Par. 21..22 and 23..24).
0 Disabled (Default).
1 Enabled
27 AI1 offset calibration
(Word modbus )
28 AI2 offset calibration (Word modbus )
Offset calibration. Value added to or taken from the process displayed
-10000..+10000 [digit]. Default 0.
29 AI1 gain calibration
(Word modbus )
30 AI2 gain calibration (Word modbus )
Gain calibration. Value to be multiplied by the process to calibrate on the operating point. E.g.: to
correct the 0..1000 operating scale that displays 0..1010, set the parameter to -1.0
-1000 (100.0%)...+1000 (+100.0%), Default: 0.0.
31 Reserved
(Word modbus )
32 Reserved (Word modbus )
33 AI1 input filter (Word modbus )
34 AI2 input filter (Word modbus )
Analog input reading filter: it increases the stability of the reading of the corresponding analog
input. Indicates the number of samples to average in the process calculation.
1...30. (Default: 10)
