60 - MCM260X - Manuale d’uso
bit 8 FRam memory error
bit 9 terminal offline
bit 10 NFC password not set
bit 11 low power supply voltage
bit 12 AI1 out of range
bit 13 AI2 out of range
bit 14 AI3 out of range
bit 15 AI4 out of range
Terminal status/error flags
(idx x, s-idx ) 16bit unsigned
bit 0 eeprom memory reading error
bit 1 eeprom memory writing error
bit 2 incorrect parameters
11. 3 Standard Device Profile Area
The table below lists all the specific Pixsys parameters supported:
Index Name Type R/W
0x6000 Digital Input Array 8bit unsigned R
0x6005 Global Interrupt enable Digital 8 bit Array 8bit unsigned R/W
0x6006 Interrupt mask any change 8 bit Array 8bit unsigned R/W
0x6007 Interrupt Mask Low-to-High 8 bit Array 8bit unsigned R/W
0x6008 Interrupt Mask High-to-Low 8 bit Array 8bit unsigned R/W
0x6200 Digital Output Array 8bit unsigned R/W
0x6206 Digital Output Error Mode Array 8bit unsigned R/W
0x6207 Digital Output Error Value Array 8bit unsigned R/W
0x6401 Read Analogue input 16bit Array 16bit unsigned R
0x6411 Write Analogue output 16bit Array 16bit unsigned R/W
0x6421 Analogue input Trigger Selection Array 8bit unsigned R/W
0x6423
Analogue input Global Interrupt
Selection
Boolean R/W
0x6424
Analogue input Interrupt Upper Limit
Integer
Array 16bit unsigned R/W
0x6425
Analogue input Interrupt Lower Limit
Integer
Array 16bit unsigned R/W
0x6426
Analogue input Interrupt Delta
Unsigned
Array 16bit unsigned R/W
0x6427
Analogue input Negative Delta
Unsigned
Array 16bit unsigned R/W
0x6428
Analogue input Positive Delta
Unsigned
Array 16bit unsigned R/W
0x6443 Analogue Output Error Mode Array 16bit unsigned R/W
0x6444 Analogue Output Error Value Array 16bit unsigned R/W
0x67FE Error Behaviour Array 8bit unsigned R/W
