Pixsys MCM260X - Table of the Configuration Parameters for the Model MCM260 X-9 AD; Unit a - General Configuration

30 - MCM260X - Manuale d’uso
8 Table of the configuration parameters for the model
MCM260X-9AD
8.1 UNIT A - GENERAL CONFIGURATION
1 Communication interface (Word modbus )
See paragraph 6.3
2 CANopen slave address
(Word modbus )
See paragraph 6.3
3 CANopen slave speed
(Word modbus )
See paragraph 6.3
4 Modbus slave address
(Word modbus )
See paragraph 6.3
5 Modbus slave speed
(Word modbus )
See paragraph 6.3
6 Modbus data format
(Word modbus )
See paragraph 6.3
7 Modbus response delay
(Word modbus )
See paragraph 6.3
8 Modbus offline time
(Word modbus )
In case of Modbus protocol enabled, it determines the time of inactivity of the serial before
stating the offline condition.
0 Offline management disabled (Default)
1..60000 [ms] Inactivity time before the offline.
9 Reserved
(Word modbus )
10 Line termination resistance status (Word modbus )
See paragraph 6.3
11 Reserved
(Word modbus )
12 Digital outputs status offline
(Word modbus )
It determines the status of the digital outputs Q1..Q16 when the module offline conditions occurs
or when starting in case of Modbus protocol enabled. Disabled = 0, Enabled = 1.
bit 0 Output Q1 status (Default 0).
...
bit 15 Output Q16 status.
13 Password to access the configuration parameters
(Word modbus )
See paragraph 6.3
14 NFC functionality block
(Word modbus )
See paragraph 6.3
15 Reserved
(Word modbus )
16 Reserved (Word modbus )
17 Reserved (Word modbus )
