Pixsys MCM260X User Manual

Manuale d’uso - MCM260X - 9
2 Composition of acronym
The MCM260X series includes the following models:
MCM260X-
MCM260X-1AD
Power supply 12..24 Vdc
16 Static Outputs 12..24Vdc
MCM260X-2AD
Power supply 12..24 Vdc
16 Digital inputs PNP 12..24Vdc
2 Analog inputs 0...10V
3 Encoders/Counters
MCM260X-3AD
Power supply 12..24 Vdc
8 Digital inputs PNP 12..24Vdc
8 Static Outputs 12..24Vdc
3 Encoders/Counters
MCM260X-4AD
Power supply 12..24 Vdc/Vac
8 Digital inputs PNP 12..24Vdc
8 Relay outputs
2 Analog inputs 0...10V
3 Encoders/Counters
MCM260X-5AD
Power supply 12..24 Vdc/Vac
4 Universal analog inputs
2 Analog outputs 0..10V / 4..20mA
MCM260X-9AD
Power supply 12..24 Vdc
4 Universal analog inputs
2 Analog outputs 0..10V / 4..20mA
16 Static outputs 12..24Vdc / Digital inputs PNP 12..24Vdc
4 Encoders/Counters
3 Technical data
3.1 General characteristics
Displays
4 0.52 inch displays
RUN, COM LEDs and I/O status LEDs
Operating
conditions
Temperature: 0-50 °C -Humidity 35..95 Rh%
Max. altitude: 2000m
Protection IP30 container
Materials
Container: Self-extinguishing polycarbonate
Front: Self-extinguishing polyamide
Weight Approximately 250 g
3.2 Hardware characteristics
3.2.a MCM260X-1AD
Power supply 12..24 Vdc ± 15% Consumption 100VA max
Digital outputs 16 static outputs 12-24Vdc
Max 700mA per output
Max 3A in total for all the outputs
Communication
port
2 modes to select:
- RS485 with Modbus RTU protocol
- CAN with CANopen protocol
Galvanically isolated
Up to 115200 baud
Up to 1Mbit
