Pixsys MCM260X User Manual

10 - MCM260X - Manuale d’uso
3.2.b MCM260X-2AD
Power supply 12..24 Vdc ± 15% Consumption 10VA max
Digital inputs 16 inputs PNP 12-24Vdc
V
IL
= 4.3V
V
IL
= 8.0V
Encoder/Counter
inputs
3 encoders/counters superimposed on
the PNP digital inputs
32 bit resolution
Maximum frequency 80KHz
Analog inputs
2 inputs 0..10V superimposed on the
digital inputs
45000 points resolution
Communication
port
2 modes to select:
- RS485 with Modbus RTU protocol
- CAN with CANopen protocol
Galvanically isolated
Up to 115200 baud
Up to 1Mbit
3.2.c MCM260X-3AD
Power supply 12..24 Vdc ± 15% Consumption 50VA max
Digital inputs 8 inputs PNP 12-24Vdc
V
IL
= 4.3V
V
IL
= 8.0V
Encoder/Counter
inputs
3 encoders/counters superimposed on
the PNP digital inputs
32 bit resolution
Maximum frequency 80KHz
Digital outputs 8 static outputs 12-24Vdc
Max 700mA per output
Max 3A in total for all the outputs
Communication
port
2 modes to select:
- RS485 with Modbus RTU protocol
- CAN with CANopen protocol
Galvanically isolated
Up to 115200 baud
Up to 1Mbit
3.2.d MCM260X-4AD
Power supply 12..24 Vdc/Vac ± 15% Consumption 20VA max
Digital inputs 8 inputs PNP 12-24Vdc
V
IL
= 4.3V
V
IL
= 8.0V
Encoder/Counter
inputs
3 encoders/counters superimposed on
the PNP digital inputs
32 bit resolution
Maximum frequency 80KHz
Analog inputs
2 inputs 0..10V superimposed on the
digital inputs
45000 points resolution
Relay outputs 8 relay outputs with single in common
Contact data:
5A at 250Vac, 30Vdc resistive load
2A at 250Vac, 30Vdc inductive load
Max exchange power
1250 VA, 150W resistive load
500 VA, 60W inductive load
Max 10A in total
Communication
port
2 modes to select:
- RS485 with Modbus RTU protocol
- CAN with CANopen protocol
Galvanically isolated
Up to 115200 baud
Up to 1Mbit
