Pixsys MCM260X User Manual

Manuale d’uso - MCM260X - 11
3.2.e MCM260X-5AD
Power supply 12..24 Vdc/Vac ± 15% Consumption 20VA max
Analog inputs
4 inputs that can be configured via
software
Thermocouples: type K, S, R, J, T, E,
N, B; automatic compensation of cold
junction at 0..50°C.
Resistance thermometers: PT100,
PT500, PT1000, Ni100, PTC1K, NTC10K
(ß 3435K)
V/I input: 0-10V, 0-20 or 4-20mA,
0-60mV, 0-1V, 0-5V.
Potentiometer: 1..150KΩ
Galvanically insulated from power
supply and communication port
16 bit resolution
Tolerance (25 °C)
+/-0.2% ±1 digit (on F.s.)
Analog outputs
2 outputs that can be configured via
software:
0-10V or 4-20mA
16 bit resolution
Sensor power
supply output
Output to power supply 0-10V or
4-20mA normalized sensors to be
connected to analog inputs
Galvanically insulated from power
supply and communication port
24 Vdc, 100mA max
Communication
port
2 modes to select:
- RS485 with Modbus RTU protocol
- CAN with CANopen protocol
Galvanically isolated
Up to 115200 baud
Up to 1Mbit
3.2.f MCM260X-9AD
Power supply 12..24 Vdc ± 15% Consumption 100VA max
Digital inputs
16 inputs PNP 12-24Vdc
(Superimposed on the digital outputs)
V
IL
= 4.3V
V
IL
= 8.0V
Encoder/Counter
inputs
4 encoders/counters superimposed on
the PNP digital inputs
32 bit resolution
Maximum frequency 80KHz
Analog inputs
4 inputs that can be configured via
software
Thermocouples: type K, S, R, J, T, E,
N, B; automatic compensation of cold
junction at 0..50°C.
Resistance thermometers: PT100,
PT500, PT1000, Ni100, PTC1K, NTC10K
(ß 3435K)
V/I input: 0-10V, 0-20 or 4-20mA,
0-60mV, 0-1V, 0-5V.
Potentiometer: 1..150KΩ
Galvanically insulated from power
supply and communication port
16 bit resolution
Tolerance (25 °C)
+/-0.2% ±1 digit (on F.s.)
Digital outputs
16 static outputs 12-24Vdc
(superimposed on the digital inputs)
Max 700mA per output
Max 2A in total for each group of 8
outputs (Q.1-Q.8 and Q.9-Q.16)
Analog outputs
2 outputs that can be configured via
software:
0-10V or 4-20mA
16 bit resolution
Sensor power
supply output
Output to power supply 0-10V or
4-20mA normalized sensors to be
connected to analog inputs
Galvanically insulated from power
supply and communication port
24 Vdc, 100mA max
Communication
port
2 modes to select:
- RS485 with Modbus RTU protocol
- CAN with CANopen protocol
Galvanically isolated
Up to 115200 baud
Up to 1Mbit
