Manuale d’uso - MCM260X - 65
11. 3.14 Analogue Input Interrupt Lower Limit Integer
This object enables the monitoring through analog input threshold. If configured in the 0x6423
object, transmission takes place if the value is ≤ of the threshold value when a trigger condition is set.
Index Subindex Name Type Default R/W
0x6425 0
Number of analog
inputs
Array 8bit unsigned
2 MCM260X-2AD
2 MCM260X-4AD
4 MCM260X-5AD
4 MCM260X-9AD
R
1
Lower limit
1st input
Array 16bit signed 0 R/W
2
Lower limit
2nd input
Array 16bit signed 0 R/W
3
Lower limit
3rd input
Array 16bit signed 0 R/W
4
Lower limit
4th input
Array 16bit signed 0 R/W
11. 3.15 Analogue Input Interrupt Delta Unsigned
If enabled, it conditions the transmission of the current value of the analog input with the previously
transmitted value. The new value is transmitted only if higher than the previous + Delta, or if lower
than the previous – Delta.
Index Subindex Name Type Default R/W
0x6426 0
Number of analog
inputs
Array 8bit unsigned
2 MCM260X-2AD
2 MCM260X-4AD
4 MCM260X-5AD
4 MCM260X-9AD
R
1 1st input delta Array 16bit unsigned 0 R/W
2 2nd input delta Array 16bit unsigned 0 R/W
3 3rd input delta Array 16bit unsigned 0 R/W
4 4th input delta Array 16bit unsigned 0 R/W
11. 3.16 Analogue Input Interrupt Negative Delta Unsigned
If enabled, it conditions the transmission of the current value of the analog input with the previously
transmitted value. The new value is transmitted only if lower than the previous – Delta.
Index Subindex Name Type Default R/W
0x6427 0
Number of analog
inputs
Array 8bit unsigned
2 MCM260X-2AD
2 MCM260X-4AD
4 MCM260X-5AD
4 MCM260X-9AD
R
1 1st input delta Array 16bit unsigned 0 R/W
2 2nd input delta Array 16bit unsigned 0 R/W
3 3rd input delta Array 16bit unsigned 0 R/W
4 4th input delta Array 16bit unsigned 0 R/W
