Pixsys MCM260X User Manual

Manuale d’uso - MCM260X - 13
4.1 Electric connections
Caution! This regulator was designed and built in compliance with the Low Voltage 2014/35/UE
(LVD) and Electromagnetic compatibility 2014/30/UE (EMC) Directives. For installation in industrial
environments it is advisable to take the precautions below:
• Distinguish the power supply line from the power lines.
• Avoid proximity with contactor units, electromagnetic contactors, high power motors and use
filters in any event.
• Avoid proximity with power units, particularly if with phase control.
• The use of network filters is recommended on the power supply of the machine in which the
instrument will be installed, particular in case of 230Vac power supply.
The regulator is devised to be assembled with other machines. Therefore, the EC marking of
the regulator does not exempt the manufacturer of the system from the safety and conformity
obligations imposed for the machine as a whole.
• Wiring of 3.81 mm terminal block: use crimped tube terminals or flexible/rigid copper wire with
diameter up to 1.5 mm² / 16 AWG. Cable stripping lenght max 7 mm. Operating temperature: -40°C
÷ +130°C.
• Wiring of 5 mm terminal block: use crimped tube terminals or flexible/rigid copper wire with
diameter up to 2.5 mm² / 14 AWG. Cable stripping lenght max 9 mm. Operating temperature: -40°C
÷ +130°C.
• It is possible to connect on a single terminal two wires with same diameter comprised between 0.14
and 0.75mm2.
4.1.a MCM260X-1/2/3AD
1
+
–
12..24 VDC
2
Power supply 12..24Vdc ±15%
• 1: +Vdc
• 2: -Vdc
3
B-T
+ VDC
Power supply of the logic part of the device only. If the +Vdc voltage is taken
to clip 3 and not to clip 1, the outputs are not active.
4
+V
Common clip for digital inputs 12..24Vdc
+V I.1 I.2 I.7 I.8
5 6 11.. 12
MCM260X-2AD, MCM260X-3AD
Digital inputs PNP 24Vdc
5: Input 1
6: Input 2
7: Input 3
8: Input 4
9: Input 5
10 : Input 6
11: Input 7
12: Input 8
5 6 11.. 12
Q.1 Q.2 Q.7 Q.8
MCM260X-1AD
Static Outputs 24Vdc
5: Output 1
6: Output 2
7: Output 3
8: Output 4
9: Output 5
10 : Output 6
11: Output 7
12: Output 8
