User’s Manual of IGSW-24040T
Figure 4-5-3 Aggregation Group Configuration Page Screenshot
The page includes the following fields:
.Object Description
ï‚· Group ID
Indicates the group ID for the settings contained in the same row. Group ID
"Normal" indicates there is no aggregation. Only one group ID is valid per port.
ï‚· Port Members
Each switch port is listed for each group ID. Select a radio button to include a port
in an aggregation, or clear the radio button to remove the port from the
aggregation. By default, no ports belong to any aggregation group.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
103
