User’s Manual of IGSW-24040T
The port settings relate to the currently selected unit, as reflected by the page header. The Port Isolation Configuration screen in
Figure 4-6-6 appears.
Figure 4-6-6 Port Isolation Configuration Page Screenshot
The page includes the following fields:
Object Description
ï‚· Port
The switch interface.
ï‚· PVLAN Port Type
Displays private VLAN port types.
- Isolated: A single stand-alone VLAN that contains one promiscuous port and
one or more isolated (or host) ports. This VLAN conveys traffic between the
isolated ports and a lone promiscuous port.
- Promiscuous: A promiscuous port can communicate with all the interfaces
within a private VLAN. This is the default setting.
125
