User’s Manual of IGSW-24040T
Figure 4-9-13 DSCP Remarking Configuration Page Screenshot
The page includes the following fields:
Object Description
ï‚· Port
The logical port for the settings contained in the same row.
ï‚· DSCP Remarking
Mode
If the QoS remarking mode is set to enabled, it should be with this DSCP
remarking/correction function according to RFC2474 on this port.
ï‚· DSCP Queue Mapping
Configure the mapping table between the queue and its DSCP value that is used
for DSCP remarking if the DSCP value of incoming packets is not specified in
RCF2474.
Best Effort = DSCP (0)
186
