User’s Manual of IGSW-24040T
0: ARP frames where SHA is not equal to the SMAC address.
1: ARP frames where SHA is equal to the SMAC address.
Any: Any value is allowed ("don't-care").
 RARP SMAC Match
Specify whether frames can hit the action according to their target hardware
address field (THA) settings.
0: RARP frames where THA is not equal to the SMAC address.
1: RARP frames where THA is equal to the SMAC address.
Any: Any value is allowed ("don't-care").
 IP/Ethernet Length
Specify whether frames can hit the action according to their ARP/RARP
hardware address length (HLN) and protocol address length (PLN) settings.
0: ARP/RARP frames where the HLN is equal to Ethernet (0x06) and the (PLN) is
equal to IPv4 (0x04) must not match this entry.
1: ARP/RARP frames where the HLN is equal to Ethernet (0x06) and the (PLN) is
equal to IPv4 (0x04) must match this entry.
Any: Any value is allowed ("don't-care").
 IP
Specify whether frames can hit the action according to their ARP/RARP
hardware address space (HRD) settings.
0: ARP/RARP frames where the HLD is equal to Ethernet (1) must not match this
entry.
1: ARP/RARP frames where the HLD is equal to Ethernet (1) must match this
entry.
Any: Any value is allowed ("don't-care").
 Ethernet
Specify whether frames can hit the action according to their ARP/RARP protocol
address space (PRO) settings.
0: ARP/RARP frames where the PRO is equal to IP (0x800) must not match this
entry.
1: ARP/RARP frames where the PRO is equal to IP (0x800) must match this
entry.
Any: Any value is allowed ("don't-care").
 IP Parameters
The IP parameters can be configured when Frame Type "IPv4" is selected.
Object Description
 IP Protocol Filter
Specify the IP protocol filter for this ACE.
Any: No IP protocol filter is specified ("don't-care").
Specific: If you want to filter a specific IP protocol filter with this ACE, choose this
value. A field for entering an IP protocol filter appears.
ICMP: Select ICMP to filter IPv4 ICMP protocol frames. Extra fields for defining
ICMP parameters will appear. These fields are explained later in this help file.
198
