User’s Manual of IGSW-24040T
Figure 4-10-5 ACL Rate Limiter Configuration Page Screenshot
The page includes the following fields:
Object Description
 Rate Limiter ID
The rate limiter ID for the settings contained in the same row.
 Rate
The rate unit is packet per second (pps), configure the rate as 1, 2, 4, 8, 16, 32,
64, 128, 256, 512, 1K, 2K, 4K, 8K, 16K, 32K, 64K, 128K, 256K, 512K, or
1024K.
The 1 kpps is actually 1002.1 pps.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
