User’s Manual of IGSW-24040T
the RADIUS-assigned).
This option is only available for single-client modes, i.e.
• Port-based 802.1X
• Single 802.1X
RADIUS attributes used in identifying a QoS Class:
Refer to the written documentation for a description of the RADIUS attributes
needed in order to successfully identify a QoS Class. The User-Priority-Table
attribute defined in RFC4675 forms the basis for identifying the QoS Class in an
Access-Accept packet.
Only the first occurrence of the attribute in the packet will be considered, and to
be valid, it must follow this rule:
All 8 octets in the attribute's value must be identical and consist of ASCII
characters in the range '0' - '3', which translates into the desired QoS Class in the
range [0; 3].
 RADIUS-Assigned
VLAN Enabled
- When RADIUS-Assigned VLAN is both globally enabled and enabled
(checke
d) for a given port, the switch reacts to VLAN ID information
carried in the RADIUS Access-Accept packet transmitted by the
RADIUS server when a supplicant is successfully authenticated. If
present and valid, the port's Port VLAN ID will be changed to this VLAN
ID, the port will be set to be a member of that VLAN ID, and the port will
be forced into VLAN unaware mode. Once assigned, all traffic arriving
on the port will be classified and switched on the RADIUS-assigned
VLAN ID.
If (re-)authentication fails or the RADIUS Access-Accept packet no
longer carries a VLAN ID or it's invalid, or the supplicant is otherwise no
longer present on the port, the port's VLAN ID is immediately reverted to
the original VLAN ID (which may be changed by the administrator in the
meanwhile without affecting the RADIUS-assigned).
This option is only available for single-client modes, i.e.
• Port-based 802.1X
• Single 802.1X
For trouble-shooting VLAN assignments, use the
"Monitor→VLANs→VLAN Membership and VLAN Port" pages. These
pages show which modules have (temporarily) overridden the current
Port VLAN configuration.
RADIUS attributes used in identifying a VLAN ID:
RFC2868 and RFC3580 form the basis for the attributes used in identifying a
219
