User’s Manual of IGSW-24040T
server.
Tx
Responses
dot1xAuthBackendResp
onses
802.1X-based:
Counts the number of times
that the switch attempts to
send a supplicant's first
response packet to the
backend server. Indicates the
switch is attempting to
communicate with the
backend server. Possible
retransmissions are not
counted.
MAC-based:
Counts all the backend server
packets sent from the switch
towards the backend server
for a given port (left-most
table) or client (right-most
table). Possible
retransmissions are not
counted.
Information about the last supplicant/client that attempted to authenticate. This
information is available for the following administrative states:
Port-based 802.1X
Single 802.1X
Multi 802.1X
MAC-based Auth.
Name IEEE Name Description
MAC
Address
dot1xAuthLastEapolF
rameSource
The MAC address of the last supplicant/client.
VLAN ID
- The VLAN ID on which the last frame from the
last supplicant/client was received.
 Last Supplicant/Client
Info
Version
dot1xAuthLastEapolF
rameVersion
802.1X-based:
The protocol version number carried in the most
recently received EAPOL frame.
MAC-based:
Not applicable.
227
