Planet IGSW-24040T User Manual

User’s Manual of IGSW-24040T
The page includes the following fields:
Object Description
 Port to mirror to
Frames from ports that have either source or destination mirroring enabled are mirrored
to this port. Disabled disables mirroring.
 Switch to mirror to
Frames from ports that have either source (rx) or destination (tx) mirroring enabled are
mirrored to this switch.
 Port
The logical port for the settings contained in the same row.
Select mirror mode.
Rx only: Frames received at this port are mirrored to the mirroring port. Frames
transmitted are not mirrored.
Tx only: Frames transmitted from this port are mirrored to the mirroring port. Frames
received are not mirrored.
Disabled: Neither frames transmitted nor received are mirrored.
 Mode
Enabled: Frames received and frames transmitted are mirrored to the mirror port.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
