Point Grey Flea3 USB 3.0 Technical Reference 6 Image Acquisition
Field Bit Description
ISO_Channel [0-3]
Isochronous channel number for video data transmission
(Except for Format_6)
[4-5] Reserved
ISO_Speed [6-7]
Isochronous transmit speed code. (Except for Format_6)
0 = 100 Mbps
1 = 200 Mbps
2 = 400 Mbps
[8-15] Reserved
Operation_Mode [16]
1394 operation mode
Change control register sets of ISO_Channel and ISO_Speed registers
0 = Legacy (v1.30 compatible), 1 = 1394.b (v1.31 mode)
Camera shall start in legacy mode for backward compatibility
[17] Reserved
ISO_Channel_B [18-23]
Isochronous channel number for video data transmission of 1394.b mode
(Except for Format_6)
[24-28] Reserved
ISO_Speed_B [29-31]
Isochronous transmit speed code of 1394.b mode. (Except for Format_6)
0 = 100 Mbps
1 = 200 Mbps
2 = 400 Mbps
3 = 800 Mbps
4 = 1.6 Gbps
5 = 3.2 Gbpss
Format:
6.4.10.6 ISO_EN/CONTINUOUS_SHOT: 614h
This register allows the control of isochronous data transmission. During ISO_EN = 1 or One_Shot = 1 or Multi_Shot
=1, the register value which reflects the Isochronous packet format cannot change. Data transfer control priority is
ISO_EN > One_Shot > Multi_Shot.
Field Bit Description
ISO_EN/Continuous Shot [0]
0 = Stop ISO transmission of video data. Continuous Shot is not enabled.
1 = Start ISO transmission of video data.
[1-31] Reserved.
Format:
6.4.10.7 ONE_SHOT/MULTI_SHOT: 61Ch
This register allows the user to control single and multi-shot functionality of the camera. During ISO_EN = 1, One_Shot
= 1 or Multi_Shot =1, the register value which reflects the Isochronous packet format cannot change. Data transfer
control priority is ISO_EN > One_Shot > Multi_Shot.
Revised 9/27/2012
Copyright ©2011-2012 Point Grey Research Inc.
92
