Point Grey Flea3 USB 3.0 Technical Reference Appendix A: Control and Status Registers
Broadcast is only available for FlyCapture2 and FireWire cameras. FireWire has the ability to write to multiple cameras
at the same time.
A.1.2 Config ROM
A.1.2.1 Root Directory
Offset Bit Description
Bus Info Block
400h
[0-7] 04h
[8-15] crc_length
[16-31] rom_crc_value
404h
[0-7] 31h
[8-15] 33h
[16-23] 39h
[24-31] 34h
408h
[0-3] 0010 (binary)
[4-7] Reserved
[8-15] FFh
[16-19] max_rec
[20] Reserved
[21-23] mxrom
[24-31] chip_id_hi
40Ch
[0-23] node_vendor_id
[24-31] chip_id_hi
410h [0-31] chip_id_lo
Root Directory
414h
[0-15] 0004h
[16-31] CRC
418h
[0-7] 03h
[8-31] module_vendor_id
41Ch
[0-7] 0Ch
[8-15] Reserved
[16-31] 1000001111000000 (binary)
420h
[0-7] 8Dh
[8-31] indirect_offset
424h
[0-7] D1h
[8-31] unit_directory_offset
