Point Grey Flea3 USB 3.0 Technical Reference Appendix A: Control and Status Registers
Offset Name Field Bit Description
540h
:
57Ch
Reserved for other FEATURE_HI_INQ
580h ZOOM_INQ Same format as the BRIGHTNESS_INQ register
584h PAN_INQ Same format as the BRIGHTNESS_INQ register
588h TILT_INQ Same format as the BRIGHTNESS_INQ register
58Ch OPTICAL_FILTER_INQ Same format as the BRIGHTNESS_INQ register
A.2.4 Video Format Inquiry Registers
The following registers may be used to determine the video formats that are available with the camera.
(Bit values = 0: Not Available, 1: Available)
Offset Name Field Bit Description
100h V_FORMAT_INQ
Format_0 [0]
VGA non-compressed format
(160x120 through 640x480)
Format_1 [1]
Super VGA non-compressed format (1)
(800x600 through 1024x768)
Format_2 [2]
Super VGA non-compressed format (2)
(1280x960 through 1600x1200)
Format_x [3-5] Reserved for other formats
Format_6 [6] Still Image Format
Format_7 [7] Partial Image Size Format
[8-31] Reserved
Format:
A.2.5 Video Mode Inquiry Registers
The following registers may be used to determine the video modes that are available with the camera.
(Bit values = 0: Not Available, 1: Available)
Revised 9/27/2012
Copyright ©2011-2012 Point Grey Research Inc.
138
