Point Grey Flea3 USB 3.0 Technical Reference Appendix A: Control and Status Registers
Offset Name Field Bit Description
52Ch TEMPERATURE_INQ Same format as the BRIGHTNESS_INQ register
530h TRIGGER_INQ
Presence_Inq [0] Presence of this feature
Abs_Control_Inq [1] Absolute value control
[2-3] Reserved
ReadOut_Inq [4] Ability to read the value of this feature
On_Off_Inq [5] Ability to switch feature ON and OFF
Polarity_Inq [6] Ability to change trigger input polarity
Value_Read_Inq [7] Ability to read raw trigger input
Trigger_Source0_Inq [8] Presence of Trigger Source 0 ID=0
Trigger_Source1_Inq [9] Presence of Trigger Source 1 ID=1
Trigger_Source2_Inq [10] Presence of Trigger Source 2 ID=2
Trigger_Source3_Inq [11] Presence of Trigger Source 3 ID=3
[12-14] Reserved
Software_Trigger_Inq [15] Presence of Software Trigger ID=7
Trigger_Mode0_Inq [16] Presence of Trigger Mode 0
Trigger_Mode1_Inq [17] Presence of Trigger Mode 1
Trigger_Mode2_Inq [18] Presence of Trigger Mode 2
Trigger_Mode3_Inq [19] Presence of Trigger Mode 3
Trigger_Mode4_Inq [20] Presence of Trigger Mode 4
Trigger_Mode5_Inq [21] Presence of Trigger Mode 5
[22-29] Reserved
Trigger_Mode14_Inq [30]
Presence of Trigger Mode 14 (Vendor unique
trigger mode 0)
Trigger_Mode15_Inq [31]
Presence of Trigger Mode 15 (Vendor unique
trigger mode 1)
534h TRIGGER_DLY_INQ
Presence_Inq [0] Presence of this feature
Abs_Control_Inq [1] Absolute value control
[2] Reserved
One_Push_Inq [3]
One push mode (controlled automatically only
once)
ReadOut_Inq [4] Ability to read the value of this feature
On_Off_Inq [5] Ability to switch feature ON and OFF
[6-7] Reserved
Min_Value [8-19] Minimum value for this feature control
Max_Value [20-31] Maximum value for this feature control
538h WHITE_SHD_INQ Same format as the BRIGHTNESS_INQ register
53Ch FRAME_RATE_INQ Same format as the BRIGHTNESS_INQ register
