Point Grey Flea3 USB 3.0 Technical Reference 5 Video Formats, Modes and Frame Rates
Pixel Format 2080 x 1552 1600 x 1200 1280 x 960 640 x 480 320 x 240 160 x 120
All Formats 15 15 15 15 15 15
Mode 7
Pixel Format 2080 x 1080 1280 x 960 640 x 480 320 x 240 160 x 120
8-bit (Mono, Raw) 86 97 182 182 182
12-bit (Mono, Raw, YUV411) 60 97 182 182 182
16-bit (Mono, Raw, YUV422) 45 81 182 182 182
24-bit (YUV444, RGB) 29 55 182 182 182
In mode 8, the ROI size can range from 16 to 2080 pixels wide and 2 to 1080 pixels high, making the minimum image size 16 x 2 and the maximum size 2080 x 1080
Mode 8
5.3.5 FL3-U3-88S2 Video Modes
5.3.5.1 FL3-U3-88S2C Standard Formats, Modes and Frame Rates
Modes 1.875 FPS 3.75 FPS 7.5 FPS 15 FPS
1600 x 1200 YUV422
• • • •
1600 x 1200 RGB
• • • •
1600 x 1200 Y8
• • • •
1600 x 1200 Y16
• • • •
Modes default to highest frame rate
5.3.5.2 FL3-U3-88S2C Custom Formats, Modes and Frame Rates
Many USB 3.0 PCI Express Gen 2.0 motherboards limit data rates to ~180MByte/s. The FlyCap2
Camera Selection dialog shows the supported PCIe bus speed. If you select a video format/mode
that requires data rates above what is supported, the camera will skip images.
For example: 1920 x 1080, 60 FPS, YUV422 = ~248 MB/s
Images acquired by color cameras using Mono8, Mono12 or Mono16 modes are converted to
greyscale on the camera. Users interested in accessing the raw Bayer data to apply their own
color conversion algorithm or one of the FlyCapture library algorithms should refer to Accessing
Raw Bayer Data on page 117.
Table 5.8: FL3-U3-88S2C Custom Formats, Modes and Frame Rates
Pixel Format 4096 x 2160 1600 x 1200 1280 x 960 640 x 480 320 x 240 160 x 120
8-bit (Mono, Raw) 22 22 28 28 28 28
12-bit (Mono, Raw, YUV411) 16 28 28 28 28 28
Mode 0
Revised 9/27/2012
Copyright ©2011-2012 Point Grey Research Inc.
75
