Point Grey Flea3 USB 3.0 Technical Reference 1 Welcome to Flea3 USB 3.0
1.2 Analog-to-Digital Conversion
All CMOS camera sensors incorporates an on-chip analog to digital converter. The bit depth of the output varies
between sensors and can be seen in the table below. Image data is left-aligned across a 2-byte format. The least
significant bits, which are the unused bits, are always zero.
For example, for a 12 bit output, the least significant 4 bits will be zeros in order to fill 2 bytes. E.g. 0xFFF0.
Model Bit Depth Possible Values
FL3-U3-13S2 12 4096
FL3-U3-13Y3 10 1024
FL3-U3-13E4 10 1024
FL3-U3-32S2 12 4096
FL3-U3-88S2 12 4096
Revised 9/27/2012
Copyright ©2011-2012 Point Grey Research Inc.
12
