Point Grey Flea3 USB 3.0 Technical Reference 1 Welcome to Flea3 USB 3.0
1.3.3 Tripod Adapter Dimensions
Figure 1.12: Tripod Adapter Dimensional Diagram
1.3.4 Lens Mounting
Lenses are not included with individual cameras.
Title Article
Selecting a lens for your camera
Knowledge Base Article 345
Related Knowledge Base Articles
The FL3-U3-13S2 and FL3-U3-32S2 lens mount is compatible with CS-mount lenses. A 5 mm C-mount adapter is
included.
The FL3-U3-13Y3, FL3- U3-13E4, and FL3-U3- 88S2 lens mount is compatible with C-mount lenses. Correct focus
cannot be achieved using a CS-mount lens on a C-mount camera.
Revised 9/27/2012
