A.3.1 FORMAT_7_RESIZE_INQ: 1AC8h
This register reports all internal camera processes being used to generate images in the current video mode. For
example, users can read this register to determine if pixel binning and/or subsampling is being used to achieve a non-
standard custom image size.
This register is read-only.
Field Bit Description
Presence_Inq [0]
Presence of this feature
0: Not Available, 1: Available
[1-7] Reserved
Num_Cols [8-11]
Number of columns being binned/subsampled, minus 1
(e.g., if combining 4 columns together, this register will report a value of 3)
Num_Rows [12-15]
Number of rows binned/subsampled, minus 1
(e.g., if combining 4 columns together, this register will report a value of 3)
[16-23] Reserved
V_Pre_Color [24]
Vertical subsampling/downsampling performed before color processing
0: Off, 1: On
H_Pre_Color [25]
Horizontal subsampling/downsampling performed before color processing
0: Off, 1: On
V_Post_Color [26]
Vertical subsampling/downsampling performed after color processing
0: Off, 1: On
H_Post_Color [27]
Horizontal subsampling/downsampling performed after color processing
0: Off, 1: On
V_Bin [28]
Standard vertical binning (addition of adjacent lines within horizontal shift register)
0: Off, 1: On
H_Bin [29]
Standard horizontal binning (addition of adjacent lines within horizontal shift register)
0: Off, 1: On
V_Bayer_Bin [30]
Vertical bayer binning (addition of adjacent even/odd lines within the interline transfer buffer)
0: Off, 1: On
H_Bayer_Bin [31]
Horizontal bayer binning (addition of adjacent even/odd columns within the horizontal shift
register)
0: Off, 1: On
Format:
A.3.2 Inquiry Registers for Custom Video Mode Offset Addresses
The following set of registers indicates the locations of the custom video mode base registers. These offsets are
relative to the base offset 0xFFFF F0F0 0000.
