Point Grey Flea3 USB 3.0 Technical Reference Appendix A: Control and Status Registers
Offset Name Field Bit Description
19Ch
V_MODE_INQ_7
(Format 7)
Mode_0 [0] Format 7 Mode 0
Mode_1 [1] Format 7 Mode 1
Mode_2 [2] Format 7 Mode 2
Mode_3 [3] Format 7 Mode 3
Mode_4 [4] Format 7 Mode 4
Mode_5 [5] Format 7 Mode 5
Mode_6 [6] Format 7 Mode 6
Mode_7 [7] Format 7 Mode 7
[8-31] Reserved
A.2.6 Video Frame Rate Inquiry Registers
This set of registers allows the user to query the available frame rates for all Formats and Modes.
(Bit values = 0: Not Available, 1: Available)
Offset Name Field Bit Description
200h
V_RATE_INQ_0_0
(Format 0, Mode 0)
FrameRate_0 [0] Reserved
FrameRate_1 [1] Reserved
FrameRate_2 [2] 7.5 fps
FrameRate_3 [3] 15 fps
FrameRate_4 [4] 30 fps
FrameRate_5 [5] 60 fps
FrameRate_6 [6] 120 fps
FrameRate_7 [7] 240 fps
[8-31] Reserved
204h
V_RATE_INQ_0_1
(Format 0, Mode 1)
FrameRate_0 [0] 1.875 fps
FrameRate_1 [1] 3.75 fps
FrameRate_2 [2] 7.5 fps
FrameRate_3 [3] 15 fps
FrameRate_4 [4] 30 fps
FrameRate_5 [5] 60 fps
FrameRate_6 [6] 120 fps
FrameRate_7 [7] 240 fps
[8-31] Reserved
208h
V_RATE_INQ_0_2
(Format 0, Mode 2)
Same format as V_RATE_INQ_0_1 Register (Format 0, Mode 1)
20Ch
V_RATE_INQ_0_3
(Format 0, Mode 3)
Same format as V_RATE_INQ_0_1 Register (Format 0, Mode 1)
Revised 9/27/2012
Copyright ©2011-2012 Point Grey Research Inc.
140
