Point Grey Flea3 USB 3.0 Technical Reference Appendix A: Control and Status Registers
Offset Name Field Bit Description
210h
V_RATE_INQ_0_4
(Format 0, Mode 4)
Same format as V_RATE_INQ_0_1 Register (Format 0, Mode 1)
214h
V_RATE_INQ_0_5
(Format 0, Mode 5)
Same format as V_RATE_INQ_0_1 Register (Format 0, Mode 1)
218h
V_RATE_INQ_0_6
(Format 0, Mode 6)
Same format as V_RATE_INQ_0_1 Register (Format 0, Mode 1)
21Ch
:
21Fh
Reserved
220h
V_RATE_INQ_1_0
(Format 1, Mode 0)
FrameRate_0 [0] Reserved
FrameRate_1 [1] 3.75 fps
FrameRate_2 [2] 7.5 fps
FrameRate_3 [3] 15 fps
FrameRate_4 [4] 30 fps
FrameRate_5 [5] 60 fps
FrameRate_6 [6] 120 fps
FrameRate_7 [7] 240 fps
[8-31] Reserved
224h
V_RATE_INQ_1_1
(Format 1, Mode 1)
Same format as V_RATE_INQ_0_0 Register (Format 0, Mode 0)
228h
V_RATE_INQ_1_2
(Format 1, Mode 2)
Same format as V_RATE_INQ_0_0 Register (Format 0, Mode 0)
22Ch
V_RATE_INQ_1_3
(Format 1, Mode 3)
FrameRate_0 [0] 1.875 fps
FrameRate_1 [1] 3.75 fps
FrameRate_2 [2] 7.5 fps
FrameRate_3 [3] 15 fps
FrameRate_4 [4] 30 fps
FrameRate_5 [5] 60 fps
FrameRate_6 [6] 120 fps
FrameRate_7 [7] Reserved
[8-31] Reserved
