Point Grey Flea3 USB 3.0 Technical Reference 5 Video Formats, Modes and Frame Rates
Pixel Format 656 x 524 640 x 480 320 x 240 160 x 120
All Formats 120 120 120 120
Mode 1
Pixel Format 1328 x 1048 1280 x 960 640 x 480 320 x 240 160 x 120
All Formats 60 60 60 60 60
Mode 7
Pixel Format 688 x 504 640 x 480 320 x 240 160 x 120
All Formats 243 243 243 243
In mode 8, the maximum size of the ROI is 688 x 504. The width must be a multiple of 16.
Mode 8
Images acquired by color cameras using Mono8, Mono12 or Mono16 modes are converted to
greyscale on the camera. Users interested in accessing the raw Bayer data to apply their own
color conversion algorithm or one of the FlyCapture library algorithms should refer to Accessing
Raw Bayer Data on page 117.
Table 5.2: FL3-U3-13S2C Custom Formats, Modes and Frame Rates
Pixel Format 1328 x 1048 1280 x 960 640 x 480 320 x 240 160 x 120
8-bit (Mono, Raw) 120 120 120 120 120
12-bit (Mono, Raw, YUV411) 97 109 120 120 120
16-bit (Mono, Raw, YUV422) 73 81 120 120 120
24-bit (YUV444, RGB) 47 55 120 120 120
Mode 0
Pixel Format 656 x 524 640 x 480 320 x 240 160 x 120
All Formats 120 120 120 120
Mode 4
Pixel Format 1328 x 1048 1280 x 960 640 x 480 320 x 240 160 x 120
8-, 12-, 16-bit (Mono, Raw, YUV411, YUV422) 60 60 60 60 60
24-bit (YUV444, RGB) 48 55 60 60 60
Mode 7
Pixel Format 688 x 504 640 x 480 320 x 240 160 x 120
All Formats 243 243 243 243
In mode 8, the maximum size of the ROI is 688 x 504. The width must be a multiple of 16.
Mode 8
