3.2.6 TEMPERATURE: 82Ch
Field Bit Description
Presence_Inq [0]
Presence of this feature
0: Not Available, 1: Available
[1-19] Reserved
Value [20-31]
Value.
In Kelvin (0°C = 273.15K) in increments of one-tenth (0.1) of a Kelvin
Format:
3.2.7 PIXEL_CLOCK_FREQ: 1AF0h
Field Bit Description
Pixel_Clock_Freq [0-31] Pixel clock frequency in Hz (read-only).
Format:
3.2.8 HORIZONTAL_LINE_FREQ: 1AF4h
Field Bit Description
Horizontal_Line_Freq [0-31] Horizontal line frequency in Hz (read-only).
Format:
3.3 User Memory Channels
The camera can save and restore settings and imaging parameters via on-board configuration sets, also known as
memory channels. This is useful for saving default power-up settings, such as gain, shutter, video format and frame
rate, and others that are different from the factory defaults.
Memory channel 0 stores the factory default settings that can always be restored. Two additional memory channels
are provided for custom default settings. The camera will initialize itself at power-up, or when explicitly reinitialized,
using the contents of the last saved memory channel. Attempting to save user settings to the (read-only) factory
defaults channel will cause the camera to switch back to using the factory defaults during initialization.
The following camera settings are saved in memory channels.
Frame Rate (including Absolute Value) (page 76) Image Data Format
Current Frame Rate (page 76) Image Position and Image Size (page 145)
Current Video Mode (page 76) Current Video Format (page 76)
Camera Power (page 29) Frame Information (page 119)
Brightness (including Absolute Value) (page 95) Trigger Mode (page 84)
Auto Exposure (including Absolute Value and Range) (page
114)
Trigger Delay (including Absolute Value) (page 89)
